CENTRIFUGAL BLOWERS – SHEET METAL HOUSING
- Fan Components and Material Properties
The body and hat are made of electrostatic powder-coated sheet metal. . The protective wire cage is
made of electrostatic powder-coated steel. Steel carriers connect the motor and fan impeller to the main body. The device is capable of handling air at max.40°C.
- Fan Structure
The wings made of galvanized and manufactured in aerodynamic structure to provide regular flow. Thanks to its aerodynamic wing structure, it works quietly.
It works with low noise levels and is designed to be maintenance-free for long periods of time. Because of both suction and shooting capability, it is possible to dispose of the polluted air in the environment and fresh air to the environment. Can be installed in the desired pain. Speed can
be adjusted with speed control devices.
- Speed Control
Optional control devices can be provided.
* Speed control can be done with linear voltage regulator
- Usage Areas
BDRS centrifugal fans have low noise levels, and high-pressure properties. They save space thanks to their compact structure. It is lightweight and easy to assemble. It is resistant to corrosion by its electrostatic-painted outer body. It is installed in solid
fuel boilers and transmits the fresh air required for combustion to the combustion chamber.
