HAM Series
Plate mounted Low pressure fans designed for installation on wall panels as they are suitable for wide range on Ventilation Applications.
All models incorporate a one piece bell mouth inlet and
mounting plate manufactured from Steel. The mounting
plate assembly is protected by an electrostatic paint
finish.
All models are supplied with Bird Guard manufactured
from steel and coated with electrostatic paint finish.
All models incorporated a five blade impeller
manufactured from Galvanized steel .
Sizes from 200 to 300 are finished with an electrostatic
coating. Impellers are statically and dynamically
balanced.
All models incorporate a single Phase shaded pole asynchronous Induction motor with a squirrel Cage rotor in die cast aluminum.
Standard air direction: form (A) configuration (Motor over Impeller).
Speed (r.p.m.) 1350
Maximum absorbed power (W) 280
Maximum current (A) 1.2
POWER 230-1Ph
Maximum air volume (m3/hr) 4000
Sound pressure level (dB(A)) 58
Weight (KG) 8.6
