22 Sep

Ac Infinity – CLOUDLINE T12, 12″ Duct Fan/ W LCD Thermal Control

Product and Mounting Dimensions – Fan Unit
Duct Size: 12″
Total Dimensions: 12.28 x 17.71 x 14.05 in. (31.2 x 45.0 x 35.7 cm)
Mounting Hole-To-Hole Distance: 7.00 x 7.12 in. (17.8 x 18.1 cm)
Screw Hole Size: Ø 0.462 in. (Ø 1.18 cm)
Cord Length to Controller: 240 in. (20 feet)
Cord Length to Plug: 96 in. (8 feet)
Product and Mounting Dimensions – Controller
Total Dimensions: 5.19 x 2.91 x 1.06 in. (13.2 x 7.4 x 2.7 cm)
Hole to Hole Distance: 4.71 x 2.64 in. (12.0 x 6.7 cm)
Screw Hole Size: Ø 0.119 in (Ø 0.3 cm)
Display Size: 3.5 x 1.4 in. (9 x 3.5 cm)
Sensor Probe Length: 144 in. (12 feet)
Product Performance and Technical Specs
Total Airflow: 1604 CFM
Total Noise: 62 dBA
Static Pressure: 818 Pa
Voltage: 100-240V AC
Frequency: 50/60Hz
Max Power Draw: 250 W
Average Power Usage: 139 W
Current: 2.5 A
Power Connector Type: US Plug (NEMA 1-15 Type-A)
Operating Humidity: 35 to 85% RH
Operating Temperature: 0 to 140°F
Ingress Protection: IP 44
Fan Bearings: Dual Ball
Mounting Positions: Horizontal or Vertical
L10 Life Expectancy: 67,000 Hours
Fan Quality Approvals: CE, RoHS

22 Sep

Ac Infinity – CLOUDLINE S12, 12″ Duct Fan/ W LCD Thermal Control

Product and Mounting Dimensions – Fan Unit
Duct Size: 12″
Total Dimensions: 12.28 x 17.71 x 14.05 in. (31.2 x 45.0 x 35.7 cm)
Mounting Hole-To-Hole Distance: 7.00 x 7.12 in. (17.8 x 18.1 cm)
Screw Hole Size: Ø 0.462 in. (Ø 1.18 cm)
Cord Length to Controller: 240 in. (20 feet)
Cord Length to Plug: 96 in. (8 feet)
Product and Mounting Dimensions – Controller
Total Dimensions: 3.34 x 2.95 x 0.51 in. (8.5 x 3.6 x 1.3 cm)
Required Mounting Area: 2.95 x 0.51 in. (3.6 x 1.3 cm)
Hole to Hole Distance: 2.87 in. (7.3 cm)
Screw Hole Size: Ø 0.157 in. (Ø 0.4 cm)
Product Performance and Technical Specs
Total Airflow: 1604 CFM
Total Noise: 62 dBA
Static Pressure: 818 Pa
Voltage: 100-240V AC
Frequency: 50/60Hz
Max Power Draw: 250 W
Average Power Usage: 139 W
Current: 2.5 A
Power Connector Type: US Plug (NEMA 1-15 Type-A)
Operating Humidity: 35 to 85% RH
Operating Temperature: 0 to 140°F
Ingress Protection: IP 44
Fan Bearings: Dual Ball
Mounting Positions: Horizontal or Vertical
L10 Life Expectancy: 67,000 Hours
Fan Quality Approvals: CE, RoHS

22 Sep

Ac Infinity – CLOUDLINE T10, 10″ Duct Fan/ W LCD Thermal Control

Product and Mounting Dimensions – Fan Unit
Duct Size: 10″
Total Dimensions: 9.81 x 15.20 x 11.30 in. (24.9 x 38.6 x 28.6 cm)
Mounting Hole-To-Hole Distance: 5.90 x 5.90 in. (15.0 x 15.0 cm)
Screw Hole Size: Ø 0.472 in. (Ø 1.2 cm)
Cord Length to Controller: 240 in. (20 feet)
Cord Length to Plug: 96 in. (8 feet)Product and Mounting Dimensions – Controller
Total Dimensions: 5.19 x 2.91 x 1.06 in. (13.2 x 7.4 x 2.7 cm)
Hole to Hole Distance: 4.71 x 2.64 in. (12.0 x 6.7 cm)
Screw Hole Size: Ø 0.119 in (Ø 0.3 cm)
Display Size: 3.5 x 1.4 in. (9 x 3.5 cm)
Sensor Probe Length: 144 in. (12 feet)

Product Performance and Technical Specs
Total Airflow: 1201 CFM
Total Noise: 48 dBA
Static Pressure: 1059 Pa
Voltage: 100-240V AC
Frequency: 50/60Hz
Max Power Draw: 250 W
Average Power Usage: 136 W
Current: 2.7 A
Power Connector Type: US Plug (NEMA 1-15 Type-A)
Operating Humidity: 35 to 85% RH
Operating Temperature: 0 to 140°F
Ingress Protection: IP 44
Fan Bearings: Dual Ball
Mounting Positions: Horizontal or Vertical
L10 Life Expectancy: 67,000 Hours
Fan Quality Approvals: CE, RoHS

22 Sep

Ac Infinity – CLOUDLINE S10, 10″ Duct Fan/ W LCD Thermal Control

Product and Mounting Dimensions – Fan Unit
Duct Size: 10″
Total Dimensions: 9.81 x 15.20 x 11.30 in. (24.9 x 38.6 x 28.6 cm)
Mounting Hole-To-Hole Distance: 5.90 x 5.90 in. (15.0 x 15.0 cm)
Screw Hole Size: Ø 0.472 in. (Ø 1.2 cm)
Cord Length to Controller: 240 in. (20 feet)
Cord Length to Plug: 96 in. (8 feet)
Product and Mounting Dimensions – Controller
Total Dimensions: 3.34 x 2.95 x 0.51 in. (8.5 x 3.6 x 1.3 cm)
Required Mounting Area: 2.95 x 0.51 in. (3.6 x 1.3 cm)
Hole to Hole Distance: 2.87 in. (7.3 cm)
Screw Hole Size: Ø 0.157 in. (Ø 0.4 cm)
Product Performance and Technical Specs
Total Airflow: 1201 CFM
Total Noise: 48 dBA
Static Pressure: 1059 Pa
Voltage: 100-240V AC
Frequency: 50/60Hz
Max Power Draw: 250 W
Average Power Usage: 136 W
Current: 2.7 A
Power Connector Type: US Plug (NEMA 1-15 Type-A)
Wall Adapter Input: 100 to 120V AC
Operating Humidity: 35 to 85% RH
Operating Temperature: 0 to 140°F
Ingress Protection: IP 44
Fan Bearings: Dual Ball
Mounting Positions: Horizontal or Vertical
L10 Life Expectancy: 67,000 Hours
Fan Quality Approvals: CE, RoHS

22 Sep

Ac Infinity – CLOUDLINE T8, 8″ Duct Fan/ W LCD Thermal Control

Product and Mounting Dimensions – Fan Unit
Duct Size: 8″
Total Dimensions: 8.54 x 11.89 x 9.17 in. (21.7 x 30.2 x 12.3 cm)
Mounting Hole-To-Hole Distance: 3.94 x 3.70 in. (10.0 x 9.4 cm)
Screw Hole Size: Ø 0.217 in. (Ø 0.55 cm)
Cord Length to Controller: 240 in. (20 feet)
Product and Mounting Dimensions – Controller
Total Dimensions: 3.34 x 2.95 x 0.51 in. (8.5 x 3.6 x 1.3 cm)
Required Mounting Area: 2.95 x 0.51 in. (3.6 x 1.3 cm)
Hole to Hole Distance: 2.87 in. (7.3 cm)
Screw Hole Size: Ø 0.157 in. (Ø 0.4 cm)
Cord Length to Plug: 96 in. (8 feet)
Sensor Probe Length: 144 in. (12 feet)
Product Performance and Technical Specs
Total Airflow: 807 CFM
Total Noise: 39 dBA
Static Pressure: 746 Pa
Voltage: 100-240V AC
Frequency: 50/60Hz
Max Power Draw: 110 W
Average Power Usage: 78 W
Current: 2.27 A
Power Connector Type: US Plug (NEMA 1-15 Type-A)
Operating Humidity: 35 to 85% RH
Operating Temperature: 0 to 140°F
Ingress Protection: IP 44
Fan Bearings: Dual Ball
Mounting Positions: Horizontal or Vertical
L10 Life Expectancy: 67,000 Hours
Fan Quality Approvals: CE, RoHS

22 Sep

Ac Infinity – CLOUDLINE S8, 8″ Duct Fan/ W Inline Speed Control

Product and Mounting Dimensions – Fan Unit
Duct Size: 8″
Total Dimensions: 8.54 x 11.89 x 9.17 in. (21.7 x 30.2 x 12.3 cm)
Mounting Hole-To-Hole Distance: 3.94 x 3.70 in. (10.0 x 9.4 cm)
Screw Hole Size: Ø 0.217 in. (Ø 0.55 cm)
Cord Length to Controller: 240 in. (20 feet)
Cord Length to Plug: 96 in. (8 feet)
Product and Mounting Dimensions – Controller
Total Dimensions: 3.34 x 2.95 x 0.51 in. (8.5 x 3.6 x 1.3 cm)
Required Mounting Area: 2.95 x 0.51 in. (3.6 x 1.3 cm)
Hole to Hole Distance: 2.87 in. (7.3 cm)
Screw Hole Size: Ø 0.157 in. (Ø 0.4 cm)
Product Performance and Technical Specs
Total Airflow: 807 CFM
Total Noise: 39 dBA
Static Pressure: 746 Pa
Voltage: 100-240V AC
Frequency: 50/60Hz
Max Power Draw: 110 W
Average Power Usage: 78 W
Current: 2.27 A
Power Connector Type: US Plug (NEMA 1-15 Type-A)
Operating Humidity: 35 to 85% RH
Operating Temperature: 0 to 140°F
Ingress Protection: IP 44
Fan Bearings: Dual Ball
Mounting Positions: Horizontal or Vertical
L10 Life Expectancy: 67,000 Hours
Fan Quality Approvals: CE, RoHS

22 Sep

Ac Infinity – CLOUDLINE T6, 6″ Duct Fan/ W LCD Thermal Control

Product and Mounting Dimensions – Fan Unit
Duct Size: 6″
Total Dimensions: 7.87 x 12.60 x 8.35 in. (21.2 x 32.0 x 20.0 cm)
Mounting Hole-To-Hole Distance: 3.15 X 2.36 in. (8.0 x 6.0 cm)
Screw Hole Size: Ø 0.236 in. (Ø 0.6 cm)
Cord Length to Controller: 240 in. (20 feet)
Product and Mounting Dimensions – Controller
Total Dimensions: 5.19 x 2.91 x 1.06 in. (13.2 x 7.4 x 2.7 cm)
Hole to Hole Distance: 4.71 x 2.64 in. (12.0 x 6.7 cm)
Screw Hole Size: Ø 0.119 in (Ø 0.3 cm)
Display Size: 3.5 x 1.4 in. (9 x 3.5 cm)
Cord Length to Plug: 108 in. (9 feet)
Sensor Probe Length: 144 in. (12 feet)
Product Performance and Technical Specs
Total Airflow: 402 CFM
Total Noise: 32 dBA
Static Pressure: 503 Pa
Voltage: 100-240V AC
Frequency: 50/60Hz
Max Power Draw: 64 W
Average Power Usage: 38 W
Current: 1.67 A
Power Connector Type: US Plug (NEMA 1-15 Type-A)
Operating Humidity: 35 to 85% RH
Operating Temperature: 0 to 140°F
Ingress Protection: IP 44
Fan Bearings: Dual Ball
Mounting Positions: Horizontal or Vertical
L10 Life Expectancy: 67,000 Hours
Fan Quality Approvals: CE, RoHS

22 Sep

Ac Infinity – CLOUDLINE S6, 6″ Duct Fan/ W Inline Speed Control

Product and Mounting Dimensions – Fan Unit

Duct Size:    6″

Total Dimensions: 7.87 x 12.60 x 8.35 in. (21.2 x 32.0 x 20.0 cm)

Mounting Hole-To-Hole Distance:3.15 X 2.36 in. (8.0 x 6.0 cm)

Screw Hole Size:Ø 0.236 in. (Ø 0.6 cm)

Cord Length to Controller:180 in. (15 feet)

Product and Mounting Dimensions – Controller :

Total Dimensions:   3.34 x 2.95 x 0.51 in. (8.5 x 3.6 x 1.3 cm)

Required Mounting Area:  2.95 x 0.51 in. (3.6 x 1.3 cm)

Hole to Hole Distance: 2.87in. (7.3 cm)

Screw Hole Size:   Ø 0.157 in. (Ø 0.4 cm)

Cord Length to Plug: 108 in. (9 feet)

Product Performance and Technical Specs :

Total Airflow 402 CFM
Total Noise 32 dBA
Static Pressure 503 Pa
Voltage: 100-240V: AC
Frequency: 50/60Hz
Max Power: Draw 64 W
Average Power Usage: 38 W
Current: 1.67 A
Power Connector Type: US Plug (NEMA 1-15 Type-A)
Operating Humidity: 35 to 85% RH
Operating Temperature: 0 to 140°F
Ingress Protection: IP 44
Fan Bearings: Dual Ball
Mounting Positions: Horizontal or Vertical
L10 Life Expectancy: 67,000 Hours
Fan Quality Approvals: CE, RoHS

20 Sep

Ac Infinity – CLOUDLINE T4, 4″ Duct Fan/ W LCD Thermal Control

Product and Mounting Dimensions – Fan Unit

Duct Size:    4″

Total Dimensions: 7.40 x 11.93 x 6.93 in. (18.8 x 30.3 x 17.6 cm)

Mounting Hole-To-Hole Distance: 3.15 x 2.36 in. (8.0 x 6.0 cm)

Screw Hole Size: Ø 0.197 in. (Ø 0.5 cm)

Cord Length to Controller: 240 in. (20 feet)

Product and Mounting Dimensions – Controller:

Total Dimensions: 5.19 x 2.91 x 1.06 in. (13.2 x 7.4 x 2.7 cm)

 Hole to Hole Distance:  4.71 x 2.64 in. (12.0 x 6.7 cm)

Screw Hole Size:       Ø 0.119 in (Ø 0.3 cm)

Display Size:    3.5 x 1.4 in. (9 x 3.5 cm)

   Cord Length to Plug: 108 in. (9 feet)

   Sensor Probe Length:    144 in. (12 feet)

Product Performance and Technical Specs:

Total Airflow: 205 CFM

Total Noise: 28 dBA

Max Speed: 2800 RPM

Static Pressure: 223 Pa

Voltage: 100-240V AC

Frequency: 50/60Hz

Max Power Draw: 28 W

Average Power Usage: 21 W

Current:  1.2 A

Power Connector Type: US Plug (NEMA 1-15 Type-A)

Operating Humidity: 35 to 85% RH

Operating Temperature: 0 to 140°F

Ingress Protection: IP 44

Fan Bearings: Dual Ball

Mounting Positions: Horizontal or Vertical

L10 Life Expectancy:  67,000 Hours

Fan Quality Approvals: CE, RoHS

20 Sep

Ac Infinity – CLOUDLINE S4, 4″ Duct Fan/ W Inline Speed Control

أبعاد المنتج والتركيب – وحدة المروحة

حجم القناة:    4 “

الأبعاد الكلية: 7.40 × 11.93 × 6.93 بوصة (18.8 × 30.3 × 17.6 سم)

مسافة التركيب من الفتحة إلى الفتحة: 3.15 × 2.36 بوصة (8.0 × 6.0 سم)

حجم ثقب المسمار: Ø 0.197 بوصة (Ø 0.5 سم)

طول السلك بوحدة التحكم: 240 بوصة (20 قدمًا)

أبعاد المنتج والتركيب – وحدة التحكم:

الأبعاد الكلية:    3.34 × 2.95 × 0.51 بوصة (8.5 × 3.6 × 1.3 سم)

منطقة التركيب المطلوبة:    2.95 × 0.51 بوصة (3.6 × 1.3 سم)

المسافة من الفتحة إلى الفتحة: 2.87 بوصة. (7.3 سم)

حجم ثقب المسمار:    Ø 0.157 بوصة (Ø 0.4 سم)

طول السلك للتوصيل: 96 بوصة (8 قدم)

أداء المنتج والمواصفات الفنية:

إجمالي تدفق الهواء: 205 قدم مكعب في الدقيقة

إجمالي الضوضاء: 28 ديسيبل

السرعة القصوى: 2800 دورة في الدقيقة

ضغط ثابت: 223 باسكال

الجهد: 100-240 فولت تيار متردد

التردد: 50/60 هرتز

أقصى سحب للطاقة: 28 واط

متوسط ​​استخدام الطاقة: 21 وات

التيار:  1.2 أ

نوع موصل الطاقة: قابس أمريكي (NEMA 1-15 Type-A)

رطوبة التشغيل: 35 إلى 85٪ رطوبة نسبية

درجة حرارة التشغيل: 0 إلى 140 درجة فهرنهايت

حماية الدخول: IP 44

محامل المروحة: كرة مزدوجة

مواضع التركيب: أفقي أو رأسي

متوسط ​​العمر المتوقع L10:  67000 ساعة

موافقات جودة المروحة: CE ، RoHS

‹12345›»
